Square Downspout Pipe Roll Forming Machine

Downspout is a pipe that runs vertically along the side of the home,it is connected at the top to a hole in the gutter channel,the other end bends outward and usually sits several inches above the ground.

Description

Downspout is a pipe that runs vertically along the side of the home,it is connected at the top to a hole in the gutter channel,the other end bends outward and usually sits several inches above the ground.This allows the water to flow away from the homes it exits the pipe.A gutter is a channel installed at or just below the roof line at the edges of the home where the roof slopes downward.It is usually made of vinyl or aluminum or copper also,stainless steel .Around rain gutter has a slight downward pitch toward the corners of the home,encouraging rainwater or snow to flow "downhill" through the gutters and into the downspouts.the whole line include the downpipe roll forming machine and the downpipe bending machine.

Product Details

Parameter

No.

item

value

1

Production Capacity

12 m/min

2

Voltage

380v/220V/415V

3

Rolling thinckness

0.3-1mm

4

Feeding width

383mm

5

Cutting method

Hydraulic Cutting

6

Control system

PLC(imported Brand)

7

Speed

8-15m/min

8

Roller material

45#steel Chrome Plated

9

Cutting blade material

Cr12Mov Steel

10

Frame material

300/350mmmm H-Beam

11

Shaft material

45# Steel Outer Diameter: 60mm

12

Certification

CE ISO

13

Dimension(L*W*H)

6500*900*1500

14

Weight

3300kgs
