Photovoltaic Support C Channel Strut Making Machine
Our advanced PV bracket forming machine is engineered for precision manufacturing of solar mounting systems, delivering exceptional efficiency and structural reliability for utility-scale, commercial, and residential applications.
Description
Photovoltaic Support C Channel Strut Making Machine
Our advanced PV bracket forming machine is engineered for precision manufacturing of solar mounting systems, delivering exceptional efficiency and structural reliability for utility-scale, commercial, and residential applications.
Product Details
- 1 Multi-Station Progressive Stamping – Integrated punching, notching, bending, and forming in one automated cycle.
- 2 High-Speed Servo Drive System – 25-35 strokes/minute with ±0.1mm repeatability.
- 3 Heavy-Duty Construction – Reinforced C-frame design handles 3T capacity for steel/aluminum up to 3mm thickness.
- 4 Smart Control System – PLC- interface with automatic thickness compensation and real-time fault diagnostics.
Parameter
| Item | Value |
| Forming stations | About 20-22 stations or according to you profile drawings |
| Machine structure | cast iron strcture |
| Rollers material | GCr15,quenching treatment:HRC58-62; Cr12, SKD11（optional） |
| Way of drive | Gearbox drive |
| Raw material request | Cold rolled or hot rolled steel,galvanized steel,SS316L, Mild Steel |
| Whole line working speed | 8-10m/min |
| Length precision | 6+-1.0mm |
| Punching system | 110 tons punching press machine(option) |
| Cutting system | servo Tracking cutting |
| Inverter | Siemens,Mitsubishi, panasonic (option Brand) |
| PLC | Siemens,Mitsubishi, panasonic (option Brand) |
| Main Power with reducer | 22KW WH Chinese Famous |
| Cutting holder | Servo following cutting |
| Motor power of hydraulic station | 5.5KW |
| Cutting type | Hydraulic drive, cut after forming |
| Material of cutting blade | Cr12Mov , quenching process |
